Methanol Generator Set

Product Description

Our methanol generator set is a clean low-carbon power unit fueled by liquid methanol (CH₃OH). Compared with diesel gensets, it cuts down soot and nitrogen oxide emissions greatly. Methanol stores and transports easily in liquid form at ambient temperature. This unit supports off-grid standby power, continuous base load, CHP cogeneration and hybrid solar-battery-methanol systems, widely used for industrial plants, mining sites, ports and marine auxiliary power.

Product Advantages

1.High Efficiency & Cost Savings
The Methanol Generator Set offers excellent energy efficiency, reducing fuel consumption and lowering operating costs.

2.Reliable Performance & Durability
Designed for long-lasting performance, it provides consistent power output with robust construction for a reliable operation.

3.Eco-Friendly Power Generation
Utilizing methanol as fuel, it significantly reduces harmful emissions, providing a cleaner and more sustainable energy solution.

Product Specifications

Product name	Methanol generator set
Fuel oil	Methanol
Speed	1500RPM1500
Frequency	50/60Hz50/60
MOQ	1 set
Warranty	12months
Key Selling Points	Eco-Friendly
Rated power	300kw300
Start the system with	24V electric start-up
Weight	2900kg
Core Components	Motor
Type	Generator
Output Voltage	230
Size尺寸	3100*1250*1700mm
Connection type	Three-phase four-wire

More scenes

It can be expanded into a higher power generation system through module stacking, meeting the demand for high-power electricity. It can be applied in scenarios such as distributed power generation, hospitals, computer rooms, data centers, civil defense engineering, marine power supply, and rail transit. Our high-temperature proton exchange membrane fuel cell technology uses methanol as fuel to achieve hydrogen energy production and use for power generation, without the need for hydrogen storage and transportation. Due to the use of methanol as fuel, the liquid is safe, and transportation and refueling are relatively convenient.

Core Advantages of Methanol Generator Set

1. Ultra-low Emission & Eco-friendly

Near zero smoke, zero sulfur, extremely low NOx and particulate matter. PM emission reduced by up to 99%, NOx reduced by over 60% compared with diesel generators. Fully compliant with strict environmental and maritime emission regulations. Green methanol supportable for carbon-neutral power solutions.

2. Low Operation & Fuel Cost

Methanol is much cheaper than diesel in bulk purchase. Lower per-kWh power generation cost, effectively reduces long-term operational expenses. Cleaner combustion brings fewer carbon deposits, longer engine service intervals and lower maintenance costs.

3. Safe & Easy Fuel Storage & Transportation

Methanol is liquid at normal temperature and pressure, no high-pressure or cryogenic storage required unlike LNG. Compatible with conventional fuel tank facilities, no heavy infrastructure investment needed. Much safer and more convenient for remote sites, industrial parks and marine vessels.

4. Stable & Continuous Power Supply

Specially modified alcohol-resistant engine, professional ECU control system and cold-start technology support 24-hour full-load continuous operation. Wide power range from 30kW to 1000kW+, available for prime power and standby power applications.

5. Multiple Customized Types

Open type, silent type, containerized skid-mounted type, mobile trailer type optional. Support parallel operation, 50Hz/60Hz, CE/EAC/CCS certification available for global export and marine projects.

6. Wide Application Scenarios

Perfect for industrial factory power backup, off-grid mining & oilfield stations, marine auxiliary power, micro-grid energy storage matching, remote charging stations and overseas engineering projects.
