LPG Generator Set

Product Overview

LPG Generator Set is a dedicated power generation unit that uses liquefied petroleum gas (LPG) as fuel to produce stable AC power. LPG is a clean, low-emission fuel with convenient storage and transportation.
This genset adopts a special gas mixing system and anti-corrosion engine structure, which can adapt to LPG fuel characteristics. It supports off-grid independent power supply and grid-connected parallel operation. Optional CHP cogeneration system recycles waste heat to improve overall energy efficiency. It is an ideal backup and continuous power solution for areas without natural gas pipelines, commercial sites, remote stations and residential communities.

Main Advantages & Features

1.Clean & Low Emission
LPG burns fully, with low carbon monoxide and NOx emissions, less pollution, meets environmental requirements. No heavy soot compared with diesel generators.

2.Convenient Fuel Supply
LPG is stored in gas cylinders or tanks, no fixed gas pipeline required. Easy to transport and stock fuel, suitable for areas without pipeline natural gas.

3.Stable & Reliable Operation
Special gas carburetor and air-fuel ratio control module, stable combustion, low failure rate, long continuous running time. Built-in multiple safety protection functions.

4.Complete Safety Protection System
Equipped with gas leakage detection, overspeed, high water temperature, low oil pressure, overload, overvoltage protection and emergency stop. Automatically shut down once faults occur to protect the whole unit.

5.Smart Control System
Digital LCD controller displays real-time data: power, voltage, current, running hours, temperature. Optional ATS automatic transfer switch, remote start & stop, cloud remote monitoring.

6.Flexible Configuration Options
Open frame, silent canopy, containerized package optional. 50Hz / 60Hz, multiple voltage options. Single phase / three phase available.

7.CHP Cogeneration Optional
Recycle jacket water and exhaust heat for heating, hot water supply. The comprehensive energy efficiency can reach over 80%, greatly reducing energy cost.

Technical Parameters

Item	Specification
Product Name	LPG Generator Set / Liquefied Petroleum Gas Generator Set
Power Range	10kW ~ 800kW (Customizable)
Fuel	Liquefied Petroleum Gas (LPG)
Cooling Type	Closed water cooling / Air cooling (small power)
Rated Frequency	50Hz / 60Hz
Rated Voltage	230/400V, 415V, 480V, single / three phase
Power Factor	0.8 lag
Starting System	24V DC electric start, auto start optional
Alternator	Brushless synchronous alternator, IP23
Operation Mode	Off-grid standalone / Grid-tie parallel
Optional Accessories	Silent canopy, container, ATS cabinet, CHP heat exchanger, gas pressure regulator
Certificate	CE, ISO9001

Application Scenarios

1.Commercial backup power: Shopping malls, supermarkets, hotels, restaurants, office buildings
2. Residential community & villa backup power supply
3.Remote communication base stations, monitoring stations
4. Outdoor construction sites, mobile camps, tourism scenic spots
5. Small factories, workshops without natural gas pipeline
6. Greenhouses, farms, livestock breeding bases
7. Distributed energy and CHP heating projects
