T50 ISO Tank Container

A standardized container for transporting non-refrigerated pressurized liquefied gases (e.g., LPG, propane, anhydrous ammonia), compliant with ISO 1496/3, IMDG, and ADR standards.

Tel: +86-373-2677103

Detailed introduction

A standardized container for transporting non-refrigerated pressurized liquefied gases (e.g., LPG, propane, anhydrous ammonia), compliant with ISO 1496/3, IMDG, and ADR standards.

Design:

Pressure vessel: High-strength steel tank (working pressure 7–34.4 bar) to keep gases liquid at ambient temperatures; 20ft (~24,000–25,000L) or 40ft (~35,000–52,000L) capacity.
ISO frame: Fits global shipping, rail, and road infrastructure for seamless intermodal transport.
Safety features: Dual pressure relief valves, real-time level/pressure monitors, and emergency shut-off valves.

Key Traits:

No cryogenic cooling needed—relies on pressure.
Flexible for multi-mode logistics (“door-to-door” capability).
High capacity reduces per-unit transport costs.
Compatible with multiple gases (e.g., LPG, ammonia) with minimal cleaning.

Applications:

Energy (LPG/propane supply), chemicals (raw materials), agriculture (fertilizer-grade ammonia).

Product Parameters：

model	20ft	40ft
Dimension	6058mm2438mm2591mm	12192mm*2438mm2591mm
Working medium	LPG, propane, anhydrous ammonia
Operating pressure (MPa)	2.2	1.8
Empty container weight (kg)	8000	13000
Maximum gross operating weight (kg)	34000	36000
Design temperature(℃)	-40/+50
Volume(m³)	24.5	51.8
